TP-Link Gigabit PCI Express Network Adapter – TG-3468
Hardware Features
Standards and Protocols: IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3x
Interface: PCI Express, 1 × 10/100/1000 Mbps RJ45 Port, Auto-Negotiation, Auto MDI/MDIX
Network Media:
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
1000Base-T: UTP category 5, 5e cable (maximum 100m)
LED: Status
Wireless Standards: IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3x
Data Rates:
10/100/1000Mbps for Half-Duplex mode,
20/200/2000Mbps for Full-Duplex mode
Dimensions ( W x D x H ): 3.1 × 4.8 × 0.8 in (78.5 × 120.8 × 21.5mm)
Flow Control: IEEE 802.3x Flow Control (Full-Duplex)
Others
Certification: FCC, CE, RoHS, BSMI, VCCI
Package Content:
Gigabit PCI Express Network Adapter TG-3468
Quick Installation Guide
Resource CD
Low-profile Bracket
System Requirements: Windows 11/10/8.1/8/7
Environment:
Operating Temperature: 0℃~40℃ (32℉ ~104℉)
Storage Temperature: -40℃~70℃ (-40℉ ~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
